1. LINUX platform for rapid customization (resisting staticinterference up to ±8KV and fast pulse group interference up to ±2kV).
2. Industrial-grade anti-interference design.
3. Adaptive ink temperature control, unique energy algorithm.
4. Flexible DPI settings (40-1200DPI).
5. Alternating nozzle printing for better quality and longer lifespan.
6. High-performance integration capability.
Printing Solutions
Different communication protocols and SDK available, for various system integration applications.
Supports dynamic data and database printing.
High standard anti-interference design, suitable for tough working environment.
Can connect with the external encoder and sensor, easy for high efficiency and high speed applications.
Can print text, bar code, QR code, label, date, logo, number etc.
Applicable Materials
Food packages, outer boxes, beverage bottles, medicine boxes, labels, jars etc.
Widely used in food&beverage, chemical, cables, pharmaceutical, electronics and tobaccos industries.
-
TechnologyHP TIJ 2.5 Thermal Inkjet Technology
-
ResolutionVertical: 600 dpi; Horizontal: 40-1200 dpi. (Single head）
-
Communication ProtocolSupports external communication protocols such as HTTP, TCP, RS232/485, Mobus-TCP/Mobus-RTU
-
Screen7 inches color capacitive touch screen
-
DimensionsController: 207*134*34mm
Print head: 156*49*93mm
-
LanguageChinese, English, Korean, Russian, Spanish, Japanese, French, German, Italian, Turkish, Indonesian, Hungarian, Portuguese(Customization support)
-
KeyboardChinese, English, Korean, Arabic, Russian, Spanish, Japanese, French, German, Hungarian, Czech, Greek, Ukrainian(Customization support)
-
CounterOrdinary counter, the carry bit source can be set flexibly
-
Printing Height1~25.4mm
(Two printheads, free combination)
-
Printing SpeedUp to 100m/min（Fast dry cartridges）
-
Printing PerformanceThe printing frequency of QR code printing up to 50pcs/sec.
-
Supported BarcodeCodebar, Code25, Code39, Code93, Code128, UPCA, UPCE, EAN,ITF14
QR Code (GSI supported), Data Matrix (GSI supported), Grid Matrix, Maxicode, PDF417(Others upon request),Maxicode
-
Date FormatThe date format can be set flexibly
-
InterfaceEthernet interface*1
USB interface*1 (USB flash drive, scanner and auxiliary communication equipment)
DVI interface: connect to cable box or extended cable boxCable box interface: alarm kit, photocell, encoder, I/O (2 inputs 2 outputs), RS232
Extended Cable box interface: alarm kit, photocell, encoder, I/O (6 inputs 5 outputs), RS232
DC interface: power entry
DB15 interface: connect with printhead *2
-
Ink ManagementRecognize the ink type and choose the most suitable parameters automatically
Only original HP cartridges are supported
Automatic measurement system for ink consumption
-
Set upEquipped with standard side printing/down printing bracket
Optional Spring-back mechanism
-
Environment
Requirements
Operating environment: -10℃-- +55℃;Storage environment: -20℃-- +70℃;
-
Input PowerAC 100-240V/50-60Hz
-
Output Power24.0V 4A, 96.0W
-
Product CertificationCE, FCC
